Hardware
- Very rigid, CNC milled, anodized and sandblasted enclosure
- Color: Red and Black, matt
- Material: High quality AL6061-T6
- Dimension: 36.8x27.15x13.9mm, weight: 19g
- Power supply: 3 - 15V @ 25mA
- Operating temperature: -10°C to 60°C
- Latest generation, Ultra Fast
32bit ARM processor: 210 DMIPS
- MEMS sensor with 12-Axis Sensor Fusion
(rotation to 2000°/s !)
- Gold plated PCB with Pb-Free soldering
- Laser Engraved labels for perfect visibility.
- Integrated S-BUS Inverter
- 2x native Spektrum connectors
- 3x connector for power supply, 4x for servos
- Revolutionary GeoLink support (GPS, vario, logger)
- Spirit Aero support (from 1.4.0 Aero firmware)
- All-pin protection
- Redundant internal power chain for maximum safety
- Excessive tolerance for brown-outs
Package content
- Spirit 2 unit
- USB interface
- 15cm receiver cables
- 10cm 3M VHB doublesided adhesive tape
Warranty
- 2 year warranty for the original purchaser
- 50% discount for damage replacement of the unit
|
Features
- Super-smooth flight control
- Paddle simulation with inexpressible feeling
- Classic flybar mechanics support
- Extreme vibration immunity for all helicopter types
- Spectrum analysis for model diagnostics
- Flight log with recorded events
- Easy configuration with setup wizard
- Smartphone or tablet support via Bluetooth and WiFi
(Modules are sold separately)
- Spektrum, Jeti, OpenTX and HoTT radio integration
- Available for Windows, OSX, Linux, Android, iOS,
WP, SailfishOS, FreeBSD, Raspberry Pi and more
- Stabilisation for scale pilots and beginners
- Reliable, full-featured rescue system
- Integrated Bank Switching
- Governor for Electric, Nitro and Gasser Helicopters
- BEC tester with load verification
- Support for PWM, Futaba S-BUS, PPM,
Spektrum DSM2/DSMX, JETI Duplex EX Bus,
SRXL/Graupner SUMD/JETI UDI/JR X-Bus receivers
- Support for all servo types:
1520/960/760us @ 50 - 560Hz
- Support for CCPM 90/120/135/140°
Manual
- Available at the Wiki pages.
|
